Description
The Harvia Xenio LTY45 is a power extension unit designed for the control of additional electric sauna heaters in large sauna installations. By adding the LTY45 to an existing Xenio CX30, CX45, or CX170 control setup, you can significantly expand the maximum load range — up to 38kW — allowing a single control unit to manage multiple heaters in larger commercial or residential sauna spaces.
Wall-mountable and compact, the LTY45 integrates cleanly into any sauna equipment installation. Compatible Xenio control unit and sauna heater sold separately.
How It Works
When a single Xenio control unit does not provide enough power capacity to drive all the heaters in a large sauna, the LTY45 bridges the gap. It connects to your existing CX30, CX45, or CX170 control unit and extends the maximum load capacity up to 38kW — the exact maximum depending on the type of control unit used. This makes it an essential accessory for spa facilities, commercial saunas, or any installation where multiple heaters need to operate in tandem under a single control system.
Key Features
- Expands maximum load range up to 38kW when paired with compatible Xenio controls
- Compatible with Xenio CX30, CX45, and CX170 control units
- Designed for large sauna installations with multiple electric heaters
- Wall-mountable for clean, space-efficient installation
- Supply voltage: 240V 1PH per extension box
- Compact footprint — 14.3"W × 2.9"D × 10.5"H
- Designed, engineered, and made in Finland
What's Included
- Xenio LTY45 Power Extension Unit
Product Specifications
Xenio LTY45 Power Extension Unit
| Model | Xenio LTY45 |
| Supply Voltage (per extension box) | 240V 1PH |
| Maximum Load Range | Up to 38kW (depending on control unit type) |
| Compatible Controls | Xenio CX30, CX45, CX170 |
| Dimensions (L × W × H) | 14.3" × 2.9" × 10.5"H (364 × 73 × 267 mm) |
| Weight | 6.1 lbs |
| Installation Type | Wall-Mount |
Technical Documents
| Installation & Operation Manual | Download Manual (PDF) |
| Warranty | Download Warranty (PDF) |
Why Choose the Harvia Xenio LTY45?
- Expand your Xenio control system to handle multiple heaters in large sauna installations
- Increases maximum load up to 38kW — ideal for commercial saunas and large home spas
- Compatible with the Xenio CX30, CX45, and CX170 — works across Harvia's full Xenio ecosystem
- Wall-mountable for clean, professional installations
- Designed, engineered, and made in Finland
